Communication – for example from machine to machine – is crucial when it comes to Industry 4.0. Bosch Rexroth and third-party providers therefore make solutions available for communicating on all levels via ctrlX World, the partner network of the ctrlX AUTOMATION system. Nokia, ifm electronic GmbH and WAGO Kontakttechnik GmbH & Co. KG are all new ctrlX World partners.
“Via the ctrlX World partner network, we provide solutions as apps which enable our customers to cope with complex automation tasks. When it comes to hardware, the high-performance, communicative industrial control system ctrlX CORE provides additional support. Thanks to its open, flexible architecture, this is designed to meet current and future requirements in modern factories,” explained Hans Michael Krause, Product Manager ctrlX World at Bosch Rexroth AG.
Developing 5G usage scenarios with Nokia and Bosch Rexroth
With ctrlX AUTOMATION, Ethernet communication on a factory level is possible as standard. Together with Nokia, Bosch Rexroth is also working to connect the automation system to private and factory-wide 5G campus networks and thus allow machines and driverless transport systems to communicate with each other via 5G.
Nokia’s 5G network is in operation in the new Model Factory at Bosch Rexroth’s Customer and Innovation Center in Ulm. In combination with ctrlX AUTOMATION, it allows the development of private wireless usage scenarios. In this Model Factory, “plug and produce” becomes reality. Components, modules, subsystems and system solutions identify themselves, recognize their tasks and are ready for use at the push of a button.
“4.9G and 5G will play a key role in enabling the Factory of the Future. The Nokia Digital Automation Cloud, Nokia’s industrial-grade campus solution, offers extremely low latencies and a high level of reliability with scalable capacities via standardized mobile communications technology. Nokia is a leading provider of private wireless campus solutions with over 380 customers, more than 70 of them with 5G, already using it today to accelerate their digital transformation,” explained Jochen Apel, Head of Digital Industries at Nokia.
ifm solutions for straightforward configuration and operation of IO-Link sensors
ifm electronic GmbH, a specialist for sensor technology, supports communication between machines in the smart factory too. “The growing number of sensors and actuators in machines leads to increasing demands as regards connectivity. In addition to EtherCAT as an automation bus, we together with ifm offer an easy way of parameterizing and operating IO-Link sensors,” explained Hans Michael Krause.
The IO-Link sensors and masters from ifm can be fully integrated into ctrlX AUTOMATION. They make commissioning for example easier. The ifm software is installed on the same engineering PC as ctrlX WORKS, the software and engineering toolbox from Bosch Rexroth.
Benno Kathan, CTO of the ifm group of companies, explained: “With the help of IO-Link, a number of process values can be transferred cyclically with just one sensor cable. This increases the effectiveness of the system and helps to reduce costs. The IO-Link communication with the sensors also provides excellent diagnostic and parameterizing options from a central point. Plug and play is particularly important for our customers during commissioning. Via the ctrlX World, we can make all of these benefits available to users.”
ctrlX I/O range complemented by I/O systems from WAGO
WAGO Kontakttechnik GmbH & Co. KG, a provider of connecting and automation technology as well as interface electronics, is another new ctrlX World partner. The company complements the ctrlX I/O range with tested I/O systems in the control cabinet and in the field of machine-related applications. During the first step, WAGO sets up the I/O systems for the various signal processing tasks and flexible sensor and actuator connections in ctrlX AUTOMATION. These WAGO systems support a wide range of industry-specific communication protocols, allowing applications which go beyond mechanical and plant engineering to be achieved. Customers benefit from scalable solutions for incorporating physical measured values as well as from applications and assets in areas such as building automation, energy management, shopfloor connectivity and much more.
“In the ctrlX World, we and Bosch Rexroth offer users the freedom they need for individual, adaptable solutions. As a result, they can react flexibly to the needs of their sector,” explained Marco Henkel, Vice President Technology Management at the WAGO Group.
